Basic type: 701052
- Relay (changeover contact 10 A), PhotoMOS® relay
- Pt100, Pt1000, KTY2X-6
- Thermocouple type J, L, and K
- Data logger
- service and operating hours counter
- timer function, meeting the standards and specifications for use in rail vehicles according to DIN EN 50155, DIN EN 50121, and DIN EN 45545
| General technical data | |
|---|---|
| Measuring inputs | Pt100, Pt1000, KTY2X-6; type J, type L, and type K thermocouple; 0(4) to 20 mA; NTC 5 kΩ (at 25 °C); Ni 1000 DIN 43760, Ni 1000 Landis+Gyr TK5000 |
| Outputs | 1 relay (changeover contact 10 A); 1 PhotoMOS® relay |
| Display | Dot-matrix LCD display |
| Electrical connection | PUSH IN terminals |
| Mounting | On DIN rail 35 × 7.5 mm |
| Format (W × H × D) | 22.5 mm × 93.5 mm × 61.6 mm |
- Standard industry applications
- heating and cooling technology
- railway applications
- building technology
