Basic type: 404201
For air, smoke, and exhaust gases
The type 4 ADS product acquires the negative pressure, overpressure, or differential pressure of air, smoke, and exhaust gases in ventilation, air-conditioning, and filter systems. It is suitable to switch a current circuit ON, OFF or change it over, when the actual value changes in relation to the setpoint value.
| General technical data | |
|---|---|
| Medium temperature | -15 to +60 °C |
| Setting ranges | 0.0004 to 1.5 bar differential pressure |
| Switching point accuracy | ± 15 % |
| Operating pressure | 0 to 0.5 bar |
| Protection type | IP54 |
| Contact type | 1-pole switch as toggle fine silver (Ag) |
| Cable entry | Pg 11 |
| Electrical connection | Screw connection up to 2.5 mm² conductor cross section |
