Models
-
SF-M-S STRIKO – Flat, Multilayered, Sterile
-
SF-MV-S STRIKO – Flat, Multilayered, Vacuum Supported, Sterile
-
SF-MD-S STRIKO – Flat, Multilayered, Double Effective, Sterile
-
SU-R-S STRIKO – Reverse Acting, Shear Ring, Sterile
-
SU-C-S STRIKO – Reverse Acting, C-Form Pre Scored, Sterile
Materials
Stainless steels, Inconel, nickel, special materials such as hastelloy
Nominal widths
DN 25 – DN 100
Burst pressures
from 0.3 bar (g) to 20 bar (g)
Working ratio
up to 90 %
Burst tolerance
min. +/- 5 %
Utilisation temperature range
-200°C to +260°C
Bursting disk holder
not necessary
Vacuum support
not necessary / optional (depending on type)
Burst indicator
can be optionally integrated
- fragment-free opening behaviour
- ideal as single pressure relief unit or used in combination with safety valve
- vacuum resistant design
- working ratio: up to 90%
- upon request with 3D name-plate for safe detection of correct direction of installation
- ideal to protect media that tend to “cake”
