Doppler Flow Meter
Doppler Flow Meter เครื่องวัดอัตราการไหลแบบอัลตราโซนิก เหมาะสำหรับของเหลวที่มีตะกอน ฟองอากาศ หรืออนุภาคแขวนลอย ติดตั้งง่าย ไม่ต้องตัดท่อ ให้ผลการวัดแม่นยำสำหรับงานอุตสาหกรรมและระบบน้ำ
Showing all 9 results
-
Converter
AVFM 6.1
Read moreArea Velocity Flow MeterThe Area Velocity Flow Measurement method is the most common method of all flow measurements. The AVFM 6.1 Area Velocity Flow Meter uses a submersible ultrasonic sensor measuring both the level and velocity of flowing liquid to calculate flow measurement in an open channel or pipe. The sensors are mounted either inside a pipe or at the bottom of a channel, and the sensor is built to resist fouling, corrosion, and abrasion. The AVFM 6.1 Area Velocity Flow Meter can be configured with the standard submerged velocity-level sensor or with submerged velocity in combination with a separate non-contacting ultrasonic level sensor, which is suitable for highly aerated fluids or those with a high concentration of suspended solids. -
Doppler Flow Meter
DFS 5.1
Read moreDoppler Flow SwitchFlow switches are particularly useful for pump protection or to activate flow or no-flow alarms. The DFS 5.1 Doppler Flow Switch is designed to give basic process control for pipe flow measurement, recommended for difficult liquids including wastewater, cooling water, slurries, sludge, chemicals, viscous liquids, and abrasives that would usually damage contacting Doppler flow switches. The non-contacting ultrasonic sensor mounts to the outside of metal or plastic pipes, without the need to cut the pipe or shut down the flow of your process, increasing your efficiency and ultimate profitability. With no maintenance required for the Doppler flow switch, it works on any pipe diameter 12.5 mm (0.5 in) or larger and installs in just minutes.The relays in the DFS 5.1 can be set to turn ON and OFF at any flow rate between 0.075 m/s to 3 m/s (0.25 ft/s and 9.8 ft/s) in addition, the end-user could inset two links for separate ON/OFF set points or just one link for a high or low flow alarm. -
Doppler Flow Meter
FlowPulse Handheld Controller
Read morePortable Pipe Flow MonitoringThis HandHeld portable unit from Pulsar Measurement is designed for use with the FlowPulse pipe flow sensor, providing portable pipe flow monitoring and offering a toolset that allows programming of the non-contacting pipe flow sensor, monitoring, and data acquisition. The HandHeld controller connects to the pre-installed FlowPulse sensor or can operate as a self-contained kit, giving instant feedback on pipe flow via its color screen.The FlowPulse HandHeld controller is available as a stand-alone unit to use with existing FlowPulse sensors or can be purchased as a complete kit with a convenient carry case. The portable non-contacting, clamp-on, pipe flow monitoring system allows the operator to view traces and recorded data files - as well as loading and saving parameter files.Use the portable pipe flow monitoring system to complete system checks, monitor asset performance, or validate inline flow meter readings. Suitable for pump performance monitoring, industrial flow, irrigation flow, food and beverage manufacturers, pharmaceutical manufacturers, and much more! -
Doppler Flow Meter
MantaRay
Read morePortable Area Velocity Flow MeterThe MantaRay is a portable area velocity meter that measures flow using a submersible ultrasonic sensor. The unit is designed for flow surveys in open channels, partially-full sewer pipes, and surcharged pipes – making the portable open channel flow meter suitable for sewer monitoring, industrial flow monitoring, irrigation flow, and natural streams.Easy to UseThe MantaRay Portable Area-Velocity Flow Meter measures both level and velocity to calculate flow in an open channel or pipe. Calibration is simple: enter the pipe diameter or channel dimensions and the MantaRay automatically computes and displays the flow rate and total on its backlit LCD display.The ultrasonic sensor mounts inside the pipe or on the bottom of a channel with a stainless-steel mounting bracket (included) and a single screw into the bottom of the pipe or channel. No special compounds, tools, or hardware are required. The sensor is completely sealed with no orifices or ports, making it resistant to build-up and fouling. -
Doppler Flow Meter
SFM 6.1
Read moreUltrasonic non-contact Slurry Flow MeterPulsar SFM 6.1 Ultrasonic Slurry Flow Meter เครื่องวัดอัตราการไหลสำหรับ Slurry และ Dredging Application แบบ Clamp-On ติดตั้งภายนอกท่อ ไม่สัมผัสของไหล รองรับท่อหลายขนาด พร้อม Data Logger และสัญญาณ 4-20mA สำหรับงานอุตสาหกรรมและระบบขุดลอก -
Doppler Flow Meter
Stingray 2.0
Read morePortable Level Velocity LoggerThe Stingray 2.0 is a portable level-velocity logger, with free Logger Software for the calculation of flow as an open channel meter. The design is compact, portable, and battery-powered which makes it a fantastic instrument for open channel flow measurement. Using four standard Alkaline D-cell batteries to operate as a battery-powered data logger, the unit is a complete area velocity logger with an ultrasonic sensor that data logs level, velocity, and water temperature for flow monitoring through open channels, partially full sewer pipes and surcharged pipes. -
Doppler Flow Meter
SUP-FSD300
Read moreเครื่องวัดอัตราการไหลแบบอัลตราโซนิคโดปเปลอร์ SUP-FSD300เครื่องวัดอัตราการไหลแบบอัลตราโซนิคโดปเปลอร์ SUP-FSD300 เป็นเครื่องมือวัดอัตราการไหลและอัตราการไหลของน้ำในน้ำธรรมชาติหรือช่องทางและท่อส่งน้ำ ใช้งานง่ายและมีประสิทธิภาพที่เสถียร
