- Low installation costs with easy mounting.
- Long operation life with durable construction.
- Precision molding enables high repeatability.
- Side printed scale graduations allows for instantaneous flow reading saving time.
- Compact bodies require minimal panel space freeing valuable space.
| Place of Origin | Zhejiang China | Flout | SS316 | Thread | 1/2″ BSPT |
| Model NO. | LZM-15ST | Fitting | SS304 | Tube | Durable acrylic |
| Medium | 02 | Customized support | OEM, ODM, OBM | Sample | Available |
| Accuracy | ±4% | Brand Name | ZYIA | Valve | SS316 |
| Working Pressure | ≤1 Mpa | Type | Panel | O-ring | Silicon rubber |
| Model | Size(mm) | |||||||
| A | B | C | D | E | F | G | H | |
| LZM-15ST | 175 | 32 | 168 | 35 | 25 | 76 | 25 | 127 |
| Model | Range | Screw Thread | Accuracy |
| O2(L/Min) | |||
| LZM-15ST | 10-100
16-170 20-200 25-270 65-670 70-700 |
(M)1/2″ BSPT | ±4% |
