Features
- Meter is designed for thin fluids < 100 cp.
- Modular design allows for use with Output Modules, Sensors and Remote Transmitters.
- 2 Totals (Batch = Resettable, Cumulative = Non resettable); Rate of Flow, Factory calibrated in gallons or liters. Field calibratable. Includes nonvolatile totals.
- High accuracy meter
- Internal parts are simple to replace for easy maintenance.
- AAA Alkaline battery life: 2 years
Specifications
- Technology: Turbine
- Flow Range: 3.8 – 760 L/min (Size Dependant)
- Accuracy: ± 1.5% – 0.75% (Size Dependant)
- Repeatability: ± 0.3%
- Pressure Rating: 103 bar (1500 psi)
- Operating Temperature Range: -18° C – 54° C
