- Robust aluminum or stainless steel 316L field enclosure (IP65, IP67 / Type4X) .
It is so rugged, a truck can even stand on it! - Intrinsically Safe available – ATEX and IECEx approval for gas and dust applications.
- Familiar easy operation with the Fluidwell “Know one, know them all” configuration structure, saving time, cost and aggravation.
- Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.
- Analog and pulse outputs.
- Displays total and flow rate simultaneously and additional accumulated total.
- Large digit selection for flow rate or total.
- Flow rate: seven 17mm (0.67″) or 8mm (0.31″) digits.
- Total – resettable: seven 17mm (0.67″) digits.
- Accumulated total – not resettable: eleven 8mm (0.31″) digits.
- Separate engineering units for flow rate and total on the display.
- Remote control input to reset total or to lock the “clear total” button.
- LED backlight.
- Intrinsically safe according ATEX and IECEx.
- GRP, Aluminum or high grade stainless steel enclosure.
- Auto backup of settings and running totals in EEPROM memory.
- Ambient temperature: -40°C to +70°C (-40°F to 158°F).
- Various accessories are available for this product.
- Signal Inputs
- Flowmeter Inputs
- Pulse type inputs:
Reed-switch, open collector, NAMUR, NPN/PNP pulse, Sine wave (coil), active pulse signal.
- (0)4 – 20mA.
- Pulse type inputs:
- Status Inputs
- Remote control: external reset for clearing total or to disable manual clearing by the keypad.
- Flowmeter Inputs
- Signal Outputs
- Pulse outputs
- Function: Scaled pulse output according to accumulated total (e.g. a pulse every 3.25 gallons).
Max. frequency: 500Hz.
Adjustable pulse length from 0.001 sec. to 9.999 seconds.
- Type: One passive NPN transistor, active PNP transistor or isolated electro-mechanical relay.
- Function: Scaled pulse output according to accumulated total (e.g. a pulse every 3.25 gallons).
- Alarm outputs
- None.
- Analog outputs
- Function: Re-transmitting the flow rate – the output can be scaled to any range (e.g. 200 L/min to 1200 L/min).
- Type: One passive isolated, floating or loop powered 4 – 20mA output or one active (0)4 – 20mA or 0 – 10V DC output.
- Pulse outputs
- Supply
- Power Supply
- Long life Lithium battery.
- 4 – 20mA Loop-powered.
- 8 – 24V AC/DC.
- 115 – 230V AC.
- Basic: 8 – 30V DC.
- Sensor Supply
- 3.2, 8.2, 12, 24V DC.
- Power Supply
- Liquid flow measurement where re-transmission of the flow rate and/or totalizer functions or serial communication is required.
- The F-Series is your first and best choice for field mount indicators in safe and hazardous area applications. Especially in harsh weather conditions like rain, snow, sandy deserts, salty atmospheres and temperatures between -40°C up to +70°C (-40°F up to 158°F).
