- Meter Body Size: 1″
- Local/Remote Display: Local
- Display Type: Digital LCD
- Factory Calibrated For: Water like fluids
- Flow Meter Type: A1 Series – COMMERICAL GRADE METER
- Std Calibration Reports Included: Yes
- Warranty Period: 1 Year
- Competitor Model Numbers: 03N31GM
- Product Type: Rate & Totals
- Benefits & Features: 2-Year Battery Powered; 6 Digit Display – Floating Decimal; Rate of Flow; Batch & Cumulative Totals; Factory Calibrated and Field Calibratable; Add-On Output Options; FM Approved Class I, Div. I; Choice of Gallons or Liters; Custom Programmable Display (including UOM)
- Max Pressure Drop (at Max Flow in test conditions): 5 PSI
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 1.5%
- Repeatability (based on test conditions): ± 0.2%
- Recommended Strainer Size: 35 Mesh (500 Microns)
- Max. Particle Size: .018″ / .457 mm
- Operating Temp Without Local Computer or With Remote Computer: -40 to 250°F (-40 to 121°C) [Opt’l]
- Maximum Viscosity: 100 cps<br>[For viscous fluids like oils, the temperature must not fluctuate more than ±5°F to avoid accuracy fluctuations]
- Applications (always check Chemical Compatibility Guide): Water, Non-Aggressive Chemicals
- Not Suitable For Applications: DI Water
- Application Notes: Unidirectional but Display can be rotated 180°, Can mount Horizontally or Vertically, Can use for Gravity Feeds, Line must be full (no air) for proper accuracy
- Minimum Straight Pipe Dia.s: 20″ Upstream / 5″ Downstream
- Desired Straight Pipe Dia.s: 40″ Upstream / 10″ Downstream
