GENERAL SPECIFICATION
Housing
- Nominal size
-
- 40 mm
- Case material
-
- Black painted, steel
- Bezel ring material
-
- Black painted, steel
- Window material
-
- Instrument glass
- Protection rating (EN 60529)
-
- IP32
- Dial
-
- White, Aluminium
- Pointer
-
- Black, Aluminium
- Movement material
-
- Brass
Temperature
- Media temperature
-
- -20°C … +60°C
Wetted parts
- Process connection material
-
- Brass
- Bourdon tube
-
- Copper alloy
Performance
- Accuracy according to EN 837-1
-
- Class 2.5
- Min. measuring range
-
- 0 … 1 bar
- Max. measuring range
-
- 0 … 250 bar
- Type of pressure
-
- Gauge
- Vacuum
- Pressure limitation
-
- Steady: 75 % of full scale value
- Fluctuating: 60 % of full scale value
- Short time: 100 % of full scale value
- Thermal drift (reference: +20 °C)
-
- ± 0.4 % FS/10K
Weight
- Gauge
-
- 60 g
