- Meter Body Size: 4″
- Body Type: Sch 80
- Local/Remote Display: Local
- Display Type: Digital LCD
- Factory Calibrated For: Water like fluids
- Flow Meter Type: TM Series – WATER METER
- Std Calibration Reports Included: No
- Warranty Period: 1 Year
- Product Type: Rate & Totals
- Benefits & Features: 2-Year Battery Powered, 6 Digit Display – Floating Decimal, Rate of Flow, Batch & Cumulative Totals, Factory Calibrated and Field Calibratable, Replaceable Turbine Assembly, User configurable for Unit Of Measure, such as GPM, LPM and more, Custom Programmable Display (including UOM
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 3.0%
- Operating Temp Without Local Computer or With Remote Computer: 32 to 140°F (0 to 60°C) [Opt’l]
- Extended Flow Range: 40 – 60 GPM, 600 – 800 GPM<br>(Accuracy: ± >5% Full Scale)<br>Overranging damages meter and voids warranty
- Applications (always check Chemical Compatibility Guide): Waste Water, Water Treatment, Sub-Metering, Water Based Cooling Systems
- Not Suitable For Applications: Fuels, Oils, DI Water, Freezing Medias
- Application Notes: Unidirectional but Display can be rotated 180°, Can mount Horizontally or Vertically, Can use for Gravity Feeds, Accuracy can be improved with field calibration, Line must be full (no air) for proper accuracy, Do not allow fluid to freeze inside meter
- Minimum Straight Pipe Dia.s: 40″ Upstream / 20″ Downstream
- Piping Notes: Not recommended to connect to metal piping. If cavitation affects accuracy, try a flow control valve downstream of the meter.
