- Max Pressure Drop (at Max Flow in test conditions): Contact us
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 0.5% (±0.2% Opt’l) @ 3cp
- Repeatability (based on test conditions): ± 0.03%
- Maximum Viscosity: 1,000 cps
- Recommended Strainer Size: 100 Mesh (150 Microns)
- Max. Particle Size: .006″ / .149 mm
- Operating Temp Without Local Computer or With Remote Computer: 5 to 250°F (-15 to 120°C) [Opt’l]
- Max Pressure Drop (at Max Flow in test conditions): Contact us
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 0.5% (±0.2% Opt’l) @ 3cp
- Repeatability (based on test conditions): ± 0.03%
- Maximum Viscosity: 1,000 cps
- Recommended Strainer Size: 100 Mesh (150 Microns)
- Max. Particle Size: .006″ / .149 mm
- Operating Temp Without Local Computer or With Remote Computer: 5 to 250°F (-15 to 120°C) [Opt’l]
- Applications (always check Chemical Compatibility Guide): Metering clean fluids such as water based liquids for Chemical, Cosmetic, Food, and Pharmaceutical Industries
- Not Suitable For Applications: Dirty liquids
- Minimum Straight Pipe Dia.s: None
- Desired Straight Pipe Dia.s: None
- Application Notes: The meter may be mounted horizontally or vertically but must be mounted, so the rotor shafts are in a horizontal plane (see manual), For viscous liquids, the maximum allowable flow may need to be reduced to ensure the pressure drop across the meter does NOT exceed 15 PSI, Viscosities <3cps, min. flow range is 10% of the maximum flow range, Line must be full (no air) for proper accuracy
