GENERAL SPECIFICATION
- Display: Full function color LCD with backlight, wide QVGA display
- Keypad: Tactile membrane (integral with display) function keys and cursors
- Indicators: LED for ON (Power), Stand-by, Charge, Low Battery, Fault
- Power Supply: 95-265 V AC, 50-60 Hz, 30 Watts. Battery, rechargeable lead-acid (internal).
Typical 8 hour operation, dependent on options fitted - Ambient Temperature: -5 °C to 45 °C (+23 °F to 113 °F)
- Case: Medium density blended polyethylene
- Dimensions: 453 x 120 x 245 mm (17.8’’ x 4.7’’ x 9.6 inches)
- Weight: 6 kg (13 lb)
- Standard Accessories: Integral Water Catchpot and Filters
Battery Charger Supply
Data Logging
Insight Data Acquisition Software (free download)
Wake and Sleep facility (Semi-continuous monitoring)
Carry Case - Options: Min of 3 to max 9 gases in total, from a selection of 9 gases
Probe length options – 0.3, 1.0, 1.5, 2.0, 3.0 m/1, 3.3, 5, 6.5, 10 ft
Hose length options – 3 m/10 ft or 10 m/33 ft
Draft Measurement
Flow Measurement
Smoke Measurement
Analogue outputs (eight 4-20 mA outputs)
Languages – English, French, German, Italian, Spanish & Chinese; others available
External Printer
