GENERAL SPECIFICATION
Housing
- Nominal size
-
- 63 mm
- Case material
-
- Stainless steel 1.4301 / AISI 304
- Stainless steel 1.4404 / AISI 316L, optional
- Type of housing
-
- Bayonet bezel
- Bezel ring material
-
- Stainless steel 1.4301 / AISI 304
- Stainless steel 1.4404 / AISI 316L, optional
- Window material
-
- Instrument glass
- Window gasket
-
- Elastomer
- Protection rating (EN 60529)
-
- IP65
- Dial
-
- White, Aluminium
- Pointer
-
- Black, PVA
- Movement material
-
- Stainless steel
- Safety according to EN 837-1
-
- S1, with window polycarbonate or Laminated safety glass
Temperature
- Ambient temperature
-
- -20°C … +70°C
- Storage temperature
-
- -40°C … +70°C
- Media temperature
-
- -40°C … +200°C (not filled)
Wetted parts
- Process connection material
-
- Stainless steel 1.4404 / AISI 316L
- Bourdon tube
-
- Stainless steel 1.4404 / AISI 316L
Performance
- Accuracy according to EN 837-1
-
- Class 1.6
- Min. measuring range
-
- 0 … 1 bar
- Max. measuring range
-
- 0 … 1000 bar
- Type of pressure
-
- Gauge
- Compound
- Vacuum
- Pressure limitation
-
- Steady: 75 % of full scale value
- Fluctuating: 65 % of full scale value
- Short time: 100 % of full scale value
- Thermal drift (reference: +20 °C)
-
- ± 0.4 % FS/10K
Weight
- Gauge
-
- 130 g unfilled
- 180 g filled
Approval / Conformities
- ATEX
-
- Ex II 2 GDc-IM2c
