Specification
- Max Pressure Drop (at Max Flow in test conditions): 9.7 PSI
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 1.0%
- Accuracy (% of Reading) Factory Calibrated Body Only: ± 1.5%
- Repeatability (based on test conditions): ± 0.1%
- Recommended Strainer Size: 120 Mesh (125 Microns)
- Max. Particle Size: .018″ / .457 mm
- ฯperating Temp Without Local Computer or With Remote Computer: -40 to 250°F (-40 to 121°C) [Opt’l]
- Extended Flow Range: 50 – 75 GPM (190 – 284 LPM)<br>[Accuracy of the extended flow range declines and is not guaranteed]<br>Overranging damages meter and voids warranty
- Maximum Viscosity: 100 cps<br>[For viscous fluids like oils, the temperature must not fluctuate more than ±5°F to avoid accuracy fluctuations]
