Specifications
- Max Pressure Drop (at Max Flow in test conditions): 10.6 PSI
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 1.5%
- Accuracy (% of Reading) Factory Calibrated Body Only: ± 2.0%
- Repeatability (based on test conditions): ± 0.3%
- Recommended Strainer Size: 120 Mesh (125 Microns)
- Max. Particle Size: .005″ / .127 mm
- Operating Temp Without Local Computer or With Remote Computer: -20 to 180°F (-28 to 82°C) [Opt’l]
- Extended Flow Range: 12 – 15 GPM (45.4 – 56.8 LPM)<br>[Accuracy of the extended flow range declines and is not guaranteed]<br>Overranging damages meter and voids warranty
- Maximum Viscosity: 100 cps<br>[For viscous fluids like oils, the temperature must not fluctuate more than ±5°F to avoid accuracy fluctuations]
