Specifications
-
Max Pressure Drop (at Max Flow in test conditions): 7.5 PSI
- Accuracy (% of Reading) Factory Calibrated with Computer: ± 1.5%
- Accuracy (% of Reading) Factory Calibrated Body Only: ± 2.0%
- Repeatability (based on test conditions): ± 0.1%
- Recommended Strainer Size: 120 Mesh (125 Microns)
- Max. Particle Size: .005″ / .127 mm
- Operating Temp Without Local Computer or With Remote Computer: -40 to 250°F (-40 to 121°C) [Opt’l]
- Maximum Viscosity: 100 cps<br>[For viscous fluids like oils, the temperature must not fluctuate more than ±5°F to avoid accuracy fluctuations]
