GENERAL SPECIFICATION
Housing
- Nominal size
-
- 100 mm
- Window material
-
- Laminated safety glass
- Protection rating (EN 60529)
-
- IP65
- Dial
-
- White, black scale
- Pointer
-
- Black, Aluminium
- Movement material
-
- Stainless steel
Temperature
- Ambient temperature
-
- -20°C … +60°C
- Media temperature
-
- 100°C max.
Wetted parts
- Process connection material
-
- Stainless steel 1.4571 / AISI 316Ti
- Diaphragm
-
- Duratherm 600
Performance
- Accuracy according to EN 837-3
-
- Class 1.6
- Min. measuring range
-
- -1 … 0 bar with 100 mm flange
- -400 … 0 mbar with 150 mm flange
- Max. measuring range
-
- 0 … 25 bar with 100 mm flange
- 0 … 400 mbar with 150 mm flange
- Thermal drift (reference: +20 °C)
-
- ± 0.8 % FS/10K
Weight
- Gauge
-
- 1700 g for DPC with 100 mm flange
- 3000 g for DPC with 150 mm flange
- 2000 g for DPO with 100 mm flange
- 3400 g for DPO with 150 mm flange
