Showing all 3 results

  • G2S10FQ9GMD (1″)
    FLOMEC
    Read more
    Flow Measurement

    G2S10FQ9GMD (1″)

    1″ 150 lb ANSI Flange 316SS
    Rate & Totals G2 Series – INDUSTRIAL GRADE METER
    Main Specifications
    Connection Size: 1″
    Connection Type: 150 lb ANSI Flange
    Flow Range: 5 – 50 GPM (18.9 – 190 LPM)
    Pressure Rating: 255 PSI @ 140°F, 275 PSI @ 100°F
    Operating Temp With Local Computer:
    0 to 140°F (-18 to 60°C) for SAFE AREA (Non-FM Approved)
    0 to 129°F (-18 to 54°C) for INTRINSICALLY SAFE (FM Approved)
    Read more
  • G2S15FQ9GME (1-1/2")
    FLOMEC
    Read more
    Flow Measurement

    G2S15FQ9GME (1-1/2″)

    1-1/2″ 150 lb ANSI Flange 316SS
    Rate & Totals G2 Series – INDUSTRIAL GRADE METER
    Main Specifications
    Connection Size: 1-1/2″
    Connection Type: 150 lb ANSI Flange
    Flow Range: 10 – 100 GPM (38.0 – 380 LPM)
    Pressure Rating: 255 PSI @ 140°F, 275 PSI @ 100°F
    Operating Temp With Local Computer:
    0 to 140°F (-18 to 60°C) for SAFE AREA (Non-FM Approved)
    0 to 129°F (-18 to 54°C) for INTRINSICALLY SAFE (FM Approved)
    Read more
  • G2S20FQ9GME (2″)
    FLOMEC
    Read more
    Flow Measurement

    G2S20FQ9GME (2″)

    2″ 150 lb ANSI Flange 316SS
    Rate & Totals G2 Series – INDUSTRIAL GRADE METER
    Main Specifications
    Connection Size: 2″
    Connection Type: 150 lb ANSI Flange
    Flow Range: 20 – 200 GPM (76 – 760 LPM)
    Pressure Rating: 255 PSI @ 140°F, 275 PSI @ 100°F
    Operating Temp With Local Computer:
    0 to 140°F (-18 to 60°C) for SAFE AREA (Non-FM Approved)
    0 to 129°F (-18 to 54°C) for INTRINSICALLY SAFE (FM Approved)
    Read more
